UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.
Amperage Rating : 0.55 to 0.75 ABearing Type : Ceramic Radial/Carbon ThrustDimensions : 5-1/4 in W x 6-1/2 in HFrequency Rating : 60 HzImpeller Type : Composite PESMaximum Head : 19.36 ftMaximum Pressure : 145 psiPhase : 1Power Rating : 87 WSeries : UPSTemperature Rating : 140 deg FType : Canned RotorVoltage Rating : 115 VAC
Maintenance-freeLow noise and low energyComplete range and wide range of accessoriesStainless steel rotor can and bearing plateCorrosion-resistant impellerNo additional motor protection is requiredNon-electronically controlled circulator pumps for domestic building with speed controlRemovable check valveFlange pipe connectionCast iron pump housingSmall stator3-speed motor
